Dahua CS4010-8ET-60 – 10-Port Cloud Managed Desktop Switch with 8-Port PoE – Uplink & Loop Protection

Name: Dahua CS4010-8ET-60 – 10-Port Cloud Managed Desktop Switch with 8-Port PoE – Uplink &amp; Loop Protection
SKU: CAM-57147
Availability: InStock

10-Port Cloud Managed Desktop Switch with 8-Port PoE

> 8 × RJ-45 10/100 Mbps PoE ports, 2 x RJ-45 Gigabit ports.

> 60 W total PoE budget, 802.3af/at on all PoE ports, additional Hi-PoE on orange port.

> DIP switch to fast turn on/off working mode of Cloud-Managed, PoE Watchdog, Long Distance PoE.

> Wide operating temperature ranging from –10 °C to 55 °C.

> Supports VLAN and loop protection.

> WEB-managed and centralized cloud management through the DoLynk App and performs real-time monitoring of the network.

> Easy config to auto detect and set up network and security systems

₨ 14,900

10 in stock

Add to compare

Add to wishlist

Last chance! Sale ends in

00
Days

00
Hours

00
Min

00
Sec

Description
Reviews (0)

Description

Upgrade Your Networking Setup With The Dahua CS4010-8ET-60 PoE Switch

Redefine surveillance and networking with the Dahua CS4010-8ET-60 PoE Switch, a smart solution designed for modern CCTV and IP-based systems. Built for efficiency and stability, this cloud-managed desktop switch delivers both power and data through a single cable, reducing clutter and simplifying installations. From small offices to professional surveillance environments, it keeps your network organized and responsive.

This switch features intelligent cloud management, allowing remote monitoring and configuration with ease. Its robust PoE capability supports multiple devices at once, while Gigabit uplink ports ensure smooth data flow across your network. Loop protection enhances reliability by preventing network disruptions, making it a dependable choice for continuous operation. With Dahua’s engineering behind it, this switch balances performance, durability, and ease of use.

Features:

10-port design with 8 PoE ports for flexible connectivity
Cloud-managed control for remote access and monitoring
Stable PoE power output for cameras and network devices
2 Gigabit Uplink ports for efficient data transmission
Loop protection to maintain network stability

Take your network to the next level with a switch designed for real-world surveillance demands. Connect with Orient CCTV today and equip your setup with reliable Dahua networking technology that supports long-term performance and growth.

Basic

Layer

Layer 2

Switching Capacity

5.6 Gbps

Packet Forwarding Rate

4.17 Mpps

Description of Function Slots

Port 1-8: 8 × RJ-45 10/100 Mbps (PoE)
Port 9-10: 2 × RJ-45 10/100/1000 Mbps (uplink)

Operating Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

10%–90% (RH), non-condensing

Storage Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Storage Humidity

5%–95% (RH), non-condensing

Power Supply

External Power Adapter (53 V, 1.22 A)

Power Consumption

Idling: 4 W
Full load: 63 W

Statics Protection

Air discharge: 8 kV
Contact discharge: 6 kV

Lightning Protection

Common mode: 6 kV
Differential mode: 1 kV

Net Weight

0.36 kg (0.79 lb)

Gross Weight

0.92 kg (2.03 lb)

Product Dimensions

184.6 mm × 103.3 mm × 27 mm (7.27″ × 4.07″ × 1.06″) (L × W × H)

Packaging Dimensions

252 mm × 137 mm × 113 mm (9.92″ × 5.39″ × 4.45″) (L × W × H)

Casing Material

Sheet metal

Installation

Desktop mount; wall mount

Certifications

CE

PoE

Yes

PoE Power

Port 2-8≤30 W, port 1≤60 W, total≤60 W

PoE Protocol

IEEE 802.3af; IEEE 802.3at; Hi-PoE

PoE Power Consumption Management

PoE power consumption management; PoE power on/off; turns off PoE if overload is detected

PoE Pin Assignment

1,2, (V+), 3 ,6, (V-)

Long Distance PoE Transmission

Yes

Hardware

DIP Switch

Managed Mode: On by default for both local web and cloud management. Off for Unmanaged Mode.
PoE Watchdog: Monitors ports 1-8 and auto-restarts the PoE port when there is no traffic for 2 min. (Only works when Managed Mode is Off)
Extend Mode: Ports 1-8; transmission distance up to 250 meters at 10 Mbps. (Only works when Managed Mode is Off)

Reset Button

1

Performance

MTBF

2,837,361 hours

Packet Buffer Size

4 Mbit

Jumbo Frame

9216 Byte

MAC Table Size

8K

Communication Standard

IEEE 802.3; IEEE 802.3u; IEEE 802.3x; IEEE 802.3ab; IEEE 802.3az

VLAN Number

32

Feature

VLAN Function

IEEE 802.1Q VLAN

Port Feature

IEEE 802.3x Flow Control

Unknown Unicast Suppression

Multicast Storm Control

Broadcast Storm Control

MAC+Port Binding

Loop Prevention

Mirror

Local Port Mirroring
N:1 Mirroring

Reliability

LLDP

DHCP Function

DHCP Client

Security

Port Isolation

Equipment Management

Web Management

Cloud Management

Logs

Fault Alarm

General

Packing List

1 × User Manual
1 × Legal and Regulatory Information
1 × Power Cord
1 × Power Adapter

Transmission Performance:
Switch power supply voltage 54V. CAT6. Max. DC resistance < 8 Ω/100 m
Cable(m)																		Load Capacity(W)
IEEE802.3bt 90 W
100																		71.3
150																		62
200																		51
250																		40
Hi-PoE 60 W
100																		46
150																		42
200																		37
250																		32
IEEE802.3at 30 W
100																		25.5
150																		25.5
200																		25.5
250																		24
Note: Data from this table was collected by Dahua test lab and is for reference only . The actual transmission distance may vary due to power consumption of connected devices or the cable type and status.
