Want to boost your home’s security but don’t know how to add V380 ONVIF Wi-Fi cameras to your HikVision NVR? Well, you’re at the right place.

Your safety matters greatly to us, and we’re excited to help you further enhance it! With these cameras, monitoring your home from every angle becomes a breeze. Check out our V380 NVR connection guide to see just how simple setting it up can be!

Everything You Will Need

Before you start the V380 ONVIF camera setup procedure, you need to have the following:

• HikVision NVR.
• V380 ONVIF Wi-Fi camera(s).
• Network access.

You’ll need the right software and your login credentials to get started with this procedure. Plus, don’t forget to enable the ONVIF protocols on your camera.

V380 ONVIF Camera Setup

To get started, let’s set up your wireless ONVIF camera. Just follow these simple steps to begin your journey:

Configuring Wireless Camera Network (Android Users)

Preparation Before Configuration:

First, power on your camera and switch it to hotspot mode. Once you see the (MV+ID) hotspot signal in your phone’s Wi-Fi list, you’ll know your device is ready and waiting.

Configuration Steps:

1. To get started, just click the “+” button in the upper right corner of your device list and choose [Add Camera].

2. Next, simply select [Wi-Fi Smart Camera].

3. Then, go for [AP hotspot connection] and follow the prompts on your screen to keep things moving.

4. Pick the Wi-Fi network you’d like to configure your device, enter the Wi-Fi password, and click [Confirm].

5. If you’re using a device with Android 10 or lower, choose the device hotspot, and your phone will start the network configuration automatically once it’s connected.

For those with Android 10 and above: Just click [Connect AP spot] or go to your mobile phone’s [Settings], select [WLAN], and connect to the device hotspot (MV+ID). The device will automatically connect to Wi-Fi when you return to the app.

6. The camera cheerfully announces, “Wi-Fi connecting – Wi-Fi connected,” letting you know everything is perfectly set up. Then, the app sweetly lets you know with a friendly “Completed.”

Configuring Wireless Camera Network (iOS Users)

Preparation Before Configuration:

Put the camera on and switch the device to hotspot mode. Once you spot the (MV+ID) hotspot signal in your phone’s Wi-Fi list, you’ll know the device is ready and waiting for you.

Configuration Steps:

1. Start by tapping the “+” button in the top right corner of your device list, then choose [Add Camera].

2. Next, select [Wi-Fi Smart Camera].

3. Tap on [AP hotspot connection] and follow the simple prompts on your screen to keep going.

4. The system will automatically find the Wi-Fi you’re connected to; just enter your Wi-Fi password and then click [Confirm].

5. If you wish, you can click [Connect AP spot], or go to your mobile phone’s [Settings], select [Wi-Fi], and connect to the device hotspot (MV+ID). Return to the app, and the device automatically connects to Wi-Fi.

6. You’ll hear the camera say, “Wi-Fi connecting – Wi-Fi connected,” to let you know everything is set up correctly, and the app will show “Completed” to confirm it’s all done.

How To Connect Wi-Fi Kit

1. Start by powering on the base station and connecting it to the router’s LAN port.

2. Power the camera you want to connect to the Wi-Fi kit. You’ll hear voice prompts from the camera, letting you know the connection is complete.

3. Now, click the “+” button located in the upper right corner of your device list. Select [Add Camera], then choose [kit], and click [Next]. Scan the QR code on the base station, and your camera will be added to the device list under the base station.

How To Switch Wireless Camera Connection Mode?

Change Ap Hotspot Mode To Station Mode

Indoor Wireless Camera:

a) Method one: Simply press the reset button on the tail line for about 7 seconds to easily restore your device to its factory settings. This will switch it back to station mode.

b) Method two: When your device is connected to the network, just head to the lower right corner of the V380App device list screen. From there, go to [Settings] – [Replace Device Network] – then choose to switch the device to routing mode. You’ll fill in the password for your route and just hit [OK] when you’re done.

Outdoor Wireless Camera:

a) Method one: Press and hold the reset button for 10 seconds to return to the factory settings. You’ll know it’s ready when the tail indicator light stops flashing and stays steady. Just give the button a short press again, and you’ll see the tail indicator flashing slowly, which means the device is now in station mode.

b) Method two: Go to the bottom right of the V380App device list if your device is connected. Tap [Settings], then [Change Device Network]. Switch to route mode, enter your password, and hit [OK]. You’re all set.

Change Station Mode To AP Hotspot Mode

Indoor Wireless Camera:

a) Method one: Press and hold the reset button on the tail line for about 7 seconds to restore your device to factory settings. Whenever you see the prompt “waiting for Wi-Fi smart link configuration,” press the RESET button to reset. You’ll then see the message “access point established,” which means your camera is already in hotspot mode.

b) Method Two: Ensure your device is on the network, then open the V380App. On the device list, tap the lower right corner and select [Settings] – [replace device network] – [switch device to AP mode] – [OK].

Outdoor Wireless Camera:

Press the RESET button to reset your device to factory settings for about 10 seconds. You’ll know it’s working when the tail light indicator, which flashes quickly, changes to a steady light, indicating the camera is now in hotspot mode.

When your device is connected to the network, you can change its network settings easily. Just go to the lower right corner of the V380App device list screen and select [Settings]. Then, click on [Change Device Network], choose [Switch Device to AP Mode], and hit [OK] to complete the process.

Setting Up And Installing HikVision NVR

Go through the following to learn about how to set up and install HikVision NVR:

What You Need:

To set up your HikVision cameras, you’ll need a few essentials:

• The HikVision NVR,
• Precrimped CAT5E or CAT6 cables, or a friendly installer who can provide the cables with RJ45 ends (make sure to have one for each camera, plus one connecting the NVR to the modem).
• A monitor
• A screwdriver
• A ladder

Steps:

• Mark the Locations: Reference your layout plan and identify the spots where you want to install the cameras.
• Next, run the CAT6 cables to each location (one for each camera), ensuring they lead back to your NVR position.
• Remember that the NVR has a slight running fan noise, so a cupboard or walk-in space would be perfect.
• Connect and install the cameras to one end of the CAT cable, then link the other to the NVR.
• Don’t forget to seal those connections with electrical tape to guard against water ingress.
• Simply plug the monitor into the NVR using a VGA or HDMI cable to set it up. Also, connect an Ethernet cable from the NVR to your modem if you want remote viewing.
• Once everything’s plugged in, turn on the NVR and monitor, and you’ll see a setup screen appear in no time.
• Make sure to jot down the username and password you create. It can be quite a hassle to reset if you forget.
• After everything is set up, your cameras should appear on the screen.
• If you want to set up remote viewing and find yourself stuck, don’t hesitate to contact an IT professional. They can help determine if the issue lies with your modem or something else.

How To Add V380 ONVIF Wi-Fi Cameras To A HikVision NVR

Here’s how you can add V380 ONVIF Wi-Fi cameras to a HikVision NVR:

Step 1: Use tools like Advanced IP Scanner or Fing to find the camera’s IP address. Note it down for the next steps, then go to the NVR.

Step 2: Sign in to the DVR/NVR and open the camera menu

Step 3: On the DVR camera management screen, click “Custom Adding.”

Step 4: Next, add the IP camera information as displayed below:

For example:

– IP Camera Address: Camera’s Internal IP Address (For instance, 192.168.1.108)

– Protocol: HikVision

– Management Port: 8000

– Transfer Protocol: Auto

– Username: admin Password:

Step 5: After filling in all information, click the “Add button” to add the IP camera to the HikVision DVR/NVR. Check its status by looking at the icon. Watch for the “Risk Password” message in the security status, indicating a weak password. Change the camera password to something stronger. The camera name and protocol (HikVision) will also be displayed here.

Step 6: Press “Back” to see the IP camera on the DVR main screen. Your camera is now successfully added. To finish up, you’ll need to set the recording schedule for the camera to match the customers’ preferences, just like you would with any other camera.

Wrapping Up: Seamlessly Connect Your V380 Cameras to HikVision NVR

No need to worry if you’ve just purchased V380 ONVIF Wi-Fi Cameras and a HikVision NVR. We’ve prepared a simple step-by-step guide to help you easily connect your cameras to the NVR. Just follow these straightforward instructions, and you’ll have everything set up in no time!
