Hikvision DS-7116HGHI-M1 16-Channel 1080N Mini 1U H.265 DVR
Upgrade your security system with the Hikvision DS-7116HGHI-M1 — a 16-channel 1080N DVR supporting H.265 compression, multi-format input, and compact 1U design for efficient surveillance and storage.
1 Year Brand Warranty
Delivery in 3 Working Days
14 Days Seller Return Warranty
₨ 16,900
Last chance! Sale ends in
00
Hours
Hours
00
Min
Min
00
Sec
Sec
Guaranteed Safe Checkout
Description
Secure your premises with the Hikvision DS-7116HGHI-M1, a powerful 16-channel 1080N DVR designed for homes, offices, shops, and warehouses. Supporting H.265 video compression, this Mini 1U DVR offers enhanced video quality with reduced storage needs.
Whether you’re upgrading an analog system or setting up a new surveillance network, this DVR supports HDTVI, AHD, CVI, CVBS, and IP inputs, making it flexible and future-proof.
🔍 Key Features:
-
📺 16 Channels Video Input – Supports analog and IP cameras
-
🎞️ Supports 1080N/720p Resolution
-
💾 H.265 Video Compression – Save up to 50% more storage
-
🧠 Motion Detection 2.0 (Human/Vehicle Classification)
-
🎤 Audio via Coaxial Cable – 1 Audio In / 1 Audio Out
-
🌐 Remote Access via Hik-Connect App
-
🛠️ Compact Mini 1U Design – Easy to install anywhere
-
🔌 Supports SATA HDD up to 10TB
-
🔐 Security Lock Password Protection and Auto Lockout
✅ Product Specifications
| Feature | Specification |
|---|---|
| Model | DS-7116HGHI-M1 |
| Video Input | 16-ch (BNC Interface) |
| Supported Formats | HDTVI/AHD/CVI/CVBS/IP |
| Max Resolution | 1080N @ 15 fps |
| IP Video Input | Up to 2-ch (can be extended to 18-ch) |
| Audio Input/Output | 1-ch RCA / 1-ch RCA |
| Compression Format | H.265 Pro+/H.265/H.264+/H.264 |
| HDD Support | 1 SATA Interface, Up to 10TB |
| Video Output | HDMI/VGA Simultaneous Output |
| USB Ports | 2 × USB 2.0 |
| Network Interface | 1 RJ-45 10/100Mbps Ethernet Port |
| Power Supply | 12V DC / ≤7W (Without HDD) |
| Dimensions | 285 × 210 × 45 mm |
| Weight | ≤ 1.8 kg (Without HDD) |
✅ Suggested Categories
-
Hikvision DVRs
-
16-Channel DVRs
-
Analog + IP Hybrid DVRs
-
Surveillance Recording Devices
-
✅ What’s in the Box?
-
1 × DS-7116HGHI-M1 DVR
-
1 × Power Adapter
-
1 × User Manual
-
1 × Screws for Mounting
-
1 × Mouse (Optional – if bundled)
✅ Installation & Compatibility
-
Compatible with all Hikvision and third-party HD analog cameras (TVI/AHD/CVI)
-
Works with Hik-Connect mobile app and iVMS software
-
Ideal for retail shops, offices, homes, and warehouses
-
Additional information
| Weight | 1 kg |
|---|
Reviews
Clear filtersThere are no reviews yet.
