Hikvision DS-1LN6AFPSL4 Cat6A S/FTP Shielded Cable | 23 AWG Solid Copper | LSZH CPR Dca | 305m Reel-in-Box | Blue
- Fully shielded S/FTP construction for 10-Gigabit links with maximum noise immunity
- Passes Fluke 90 m permanent-link test even at continuous 50°C
- Passes Fluke 100 m channel test under continuous 57 V / 1 A PoE load
- Low-smoke zero-halogen (LSZH) sheath, CPR Dca s2 d2 a1 fire rated
- Solid bare copper 23 AWG conductors for low resistance on long runs
₨ 90,000
Last chance! Sale ends in
00
Days
Days
00
Hours
Hours
00
Min
Min
00
Sec
Sec
Description
Hikvision DS-1LN6AFPSL4 Cat6A S/FTP Shielded Cable — 10G-ready shielded Cat6A, LSZH, 305m reel-in-box
Fully shielded S/FTP construction for 10-Gigabit links with maximum noise immunity. Passes Fluke 90 m permanent-link test even at continuous 50°C.
Key Features
- Fully shielded S/FTP construction for 10-Gigabit links with maximum noise immunity
- Passes Fluke 90 m permanent-link test even at continuous 50°C
- Passes Fluke 100 m channel test under continuous 57 V / 1 A PoE load
- Low-smoke zero-halogen (LSZH) sheath, CPR Dca s2 d2 a1 fire rated
- Solid bare copper 23 AWG conductors for low resistance on long runs
Specifications
| Model | DS-1LN6AFPSL4 |
| Category | Cat6A S/FTP |
| Conductor | Solid bare copper, 0.56 mm (23 AWG) |
| Insulation Diameter | 1.33 mm |
| Sheath | LSZH, Blue |
| Fire Rating | CPR Dca s2 d2 a1 |
| Length | 305 m (±1.5 m) |
| Usage | Indoor |
| Rip Cord | Yes |
| Standards | ANSI/TIA-568.2-D, IEC 61156, ISO/IEC 11801, RoHS 2.0 |
